Clinical Benefits:

High efficiency for sharp radiography gives high-quality images.

Non-invasive diagnostic imaging equipment ensures the patient’s safety from radiation exposure.

All X-rays are compatible with IOPA Film and RVG, leading to the convenience of operations.

Key Specs:

Power adapter input: 100-240V 50/60Hz 1.5A

Internal power supply: DC 10.8V

Types of radiation: X-ray

Electric power:

Maximum power: 0.21kw（70kV, 3mA, 0.1s）

Nominal electric power: 0.21kw（70kV, 3mA, 0.1s）

Tube voltage: tube voltage output is fixed at 70kV, error ±10%

Tube current: tube current output is fixed at 3mA, error ±20%

Loading time: the exposure loading time adjustment range is 0.02s～2s, the grade is adjustable, the grade is selected according to R'10 numerical system; with deviation ±(10%+1ms)

X-ray tube:

X-ray tube model: D-045;

Focal spot: 0.4mm;

Target angle: 12.5°;

Total filtration: 1.5mmAl/70 kV;

Additional filtration: 0.5mmAl/70 kV

Distance from focus to skin: 20cm

Output radiation field: Φ6cm±0.6cm

Product specifications:

Dimension: 114mm×363.8mm×245.6mm

Weight: 2.4KG

Battery specification: 10.8V/2450~15000mAh

Operation environment :

Environment temperature: 10°C ~ 40°C

Relative humidity: 30% ~ 75%

Atmospheric pressure: 70kPa ~ 106kPa

Transportation and storage conditions:

Storage temperature: -20°C ~ 55°C

Transportation temperature: -20°C ~ 55°C

Relative humidity: 10% ~ 93%

Atmospheric pressure: 70kPa ~ 106kPa

SUPER HIGH PERFORMANCE - HIGH EFFICIENCY

Emission power up to 210W

Shorter exposure time with high power

Achieve stable, accurate, and quick photography of different tooth positions

Country of Origin: China
